class: center, middle, inverse, title-slide .title[ # Poisson and Normal (Gaussian) Distribution ] .subtitle[ ##
STA35A: Statistical Data Science 1 ] .author[ ### Xiao Hui Tai ] .date[ ### November 13, 2023 ] --- layout: true <!-- <div class="my-footer"> --> <!-- <span> --> <!-- <a href="https://datasciencebox.org" target="_blank">datasciencebox.org</a> --> <!-- </span> --> <!-- </div> --> --- <style type="text/css"> .tiny .remark-code { font-size: 70%; } .small .remark-code { font-size: 80%; } .tiny { font-size: 60%; } .small { font-size: 80%; } </style> ## Reminders: Midterm 2 - Closed-book. These formulas will be provided: - **Bayes' theorem**: `\(P(A \mid B) =\frac{P(B \mid A)P(A)}{P(B)}\)`. - **Probability mass functions**: - Binomial: `\(P(X=x)=\begin{pmatrix} n \\ x \end{pmatrix}p^x(1-p)^{n-x}\)` - Poisson: `\(P(X = x) = \frac{\lambda^x e^{-\lambda}}{x!}\)`, `\(\lambda > 0\)` - Homework 5 due Thursday 9pm, no late work - Wednesday: review, Thursday: no lab, instead OH 2:30-3:30 --- ## Recap -- - Common probability distributions: Binomial - Theoretical properties: probability mass function, parameters, mean and variance, effect of varying parameters - Sampling and law of large numbers; effect of changing parameters - R functions: - `d____()`, e.g., `dbinom()`: for densities (more accurately, for discrete random variables these are probability mass functions, `\(P(X = x)\)`) - `p____()`, e.g., `pbinom()`: for `\(P(X\leq x)\)` - `r____()`, e.g., `rbinom()`: for random sample --- ## Today - Common probability distributions - Poisson distribution - Normal or Gaussian --- ## Frequency distribution vs. probability distribution - Use `rbinom()` to get 5000 draws from the population - In R: .small[ ```r set.seed(0) # so results are reproducible binomDraws <- rbinom(n = 5000, size = 3, prob = .2) table(binomDraws)/5000 ``` ``` ## binomDraws ## 0 1 2 3 ## 0.5246 0.3638 0.1040 0.0076 ``` ] - Compare with the theoretical probabilities: .small[ ```r dbinom(x = 0:3, size = 3, prob = .2) ``` ``` ## [1] 0.512 0.384 0.096 0.008 ``` ] --- ## Frequency distribution of e-cigarette smokers ```r data.frame(binomDraws) %>% ggplot(aes(x = binomDraws)) + geom_bar() + labs(x = "Number of Smokers", title = "5000 samples from Binomial(3, .2)") ``` <img src="lecture18_files/figure-html/unnamed-chunk-5-1.png" width="60%" style="display: block; margin: auto;" /> --- ## Varying the number of Bernoulli trials: 100 trials .small[ ```r set.seed(0) # so results are reproducible binomDraws100 <- rbinom(n = 5000, size = 100, prob = .2) data.frame(binomDraws100) %>% ggplot(aes(x = binomDraws100)) + geom_bar() + labs(x = "Number of Smokers", title = "5000 samples from Binomial(100, .2)") ``` <img src="lecture18_files/figure-html/unnamed-chunk-6-1.png" width="60%" style="display: block; margin: auto;" /> ] --- ## Varying the number of Bernoulli trials: 500 trials .small[ ```r set.seed(0) # so results are reproducible binomDraws500 <- rbinom(n = 5000, size = 500, prob = .2) data.frame(binomDraws500) %>% ggplot(aes(x = binomDraws500)) + geom_bar() + labs(x = "Number of Smokers", title = "5000 samples from Binomial(500, .2)") ``` <img src="lecture18_files/figure-html/unnamed-chunk-7-1.png" width="60%" style="display: block; margin: auto;" /> ] --- ## Frequency distribution of e-cigarette smokers varying number of Bernoulli trials .small[ .pull-left[ ```r data.frame(binomDraws) %>% bind_cols(size = 3) %>% bind_rows( data.frame(binomDraws100) %>% rename(binomDraws = binomDraws100) %>% bind_cols(size = 100) ) %>% bind_rows( data.frame(binomDraws500) %>% rename(binomDraws = binomDraws500) %>% bind_cols(size = 500) ) %>% ggplot(aes(x = binomDraws, fill = as.factor(size))) + geom_histogram(binwidth = 1, position = "identity", alpha = .7) + labs( x = "Number of smokers", y = "Frequency", title = "5000 samples each from Binomial(3, .2), Binomial(100, .2), Binomial(500, .2)", fill = "Size" ) ``` ] ] .pull-right[ <img src="lecture18_files/figure-html/unnamed-chunk-9-1.png" width="100%" style="display: block; margin: auto;" /> ] --- ## Frequency distribution of e-cigarette smokers varying probability of success .small[ ```r set.seed(0) # so results are reproducible binomP.2 <- rbinom(n = 5000, size = 100, prob = .2) binomP.5 <- rbinom(n = 5000, size = 100, prob = .5) binomP.7 <- rbinom(n = 5000, size = 100, prob = .7) ``` ] <img src="lecture18_files/figure-html/unnamed-chunk-11-1.png" width="60%" style="display: block; margin: auto;" /> --- ## Poisson distribution - Useful for estimating the **number of events in a large population over a unit of time**. - For example: - The number of people having heart attacks in New York City every year - The number of accidents occurring at an intersection per hour - The number of typos in every 100 pages of a book - It is named after French mathematician Siméon Denis Poisson --- ## Poisson distribution - E.g.: Number of people having heart attacks in New York City every year - **Key ingredients** - **Fixed interval** of time or space - Events happen with a **known average rate**, independently of time since the last event ("memoryless" property) - One person having a heart attack does not change the probability of another person having a heart attack, hence the timing of the next heart attack - The parameter that defines a Poisson distributed random variable is the **rate** `\(\lambda\)`, where `\(\lambda > 0\)` - Rate = **average number of occurrences per unit of time** - Often used to model rare events --- ## Probability mass function, mean and variance - `\(P(X = x) = \frac{\lambda^x e^{-\lambda}}{x!}\)`, defined over non-negative integer values of `\(x\)` - Recall: `\(n! = n(n - 1)(n - 2)\cdots (1)\)`. - No upper limit, i.e., `\(x\)` can take very large non-negative integer values - `\(E(X) = \lambda\)` - `\(Var(X) = \lambda\)` --- ## Poisson probabilities - `\(P(X = x) = \frac{\lambda^x e^{-\lambda}}{x!}\)` lets us calculate probabilities of taking a certain value - For `\(x = 2\)` and `\(\lambda = 3\)`, we have $$ `\begin{aligned} P(X = 2) &= \frac{3^2 e^{-3}}{2!} = \frac{9(e^{-3})}{2(1)} = 0.2240418 \end{aligned}` $$ - In R: ```r dpois(x = 2, lambda = 3) ``` ``` ## [1] 0.2240418 ``` - For large values of `\(x\)`, the probability is very small because of the large denominator ```r dpois(x = 10, lambda = 3) ``` ``` ## [1] 0.0008101512 ``` --- ## Probability distribution - In the same manner, we can derive the entire probability distribution .tiny[ .pull-left[ ```r dpois(x = 0:10, lambda = 3) ``` ``` ## [1] 0.0497870684 0.1493612051 0.2240418077 0.2240418077 ## [5] 0.1680313557 0.1008188134 0.0504094067 0.0216040315 ## [9] 0.0081015118 0.0027005039 0.0008101512 ``` ```r data.frame(x = 0:10, y = dpois(0:10, lambda = 3)) %>% ggplot(aes(x = x, y = y)) + geom_bar(stat = "identity") + labs(title = "Probability distribution of Poisson(3)", y = "P(X = x)") ``` ] ] .pull-right[ <img src="lecture18_files/figure-html/unnamed-chunk-16-1.png" width="100%" style="display: block; margin: auto;" /> ] --- ## Probability distribution varying lambda .small[ ```r data.frame(x = 0:30, y = dpois(0:30, lambda = 3), lambda = 3) %>% bind_rows(data.frame(x = 0:30, y = dpois(0:30, lambda = 10), lambda = 10)) %>% bind_rows(data.frame(x = 0:30, y = dpois(0:30, lambda = 20), lambda = 20)) %>% ggplot(aes(x = x, y = y, fill = as.factor(lambda))) + geom_bar(stat = "identity", position = "identity", alpha = .5) + labs(title = "Probability distribution of \nPoisson(3), Poisson(10), Poisson(20)", y = "P(X = x)", fill = "Lambda") ``` <img src="lecture18_files/figure-html/unnamed-chunk-17-1.png" width="60%" style="display: block; margin: auto;" /> ] --- ## Sampling from Poisson distribution in R - Simulate random draws using the `rpois()` function - `rpois()` has the arguments - `n`, the number of draws from the distribution - `lambda`, the mean ```r set.seed(0) # so results are reproducible inputLambda <- 3 poissonDraws <- rpois(n = 100, lambda = inputLambda) poissonDraws ``` ``` ## [1] 5 2 2 3 5 2 5 6 4 3 1 2 1 4 2 4 3 4 8 2 4 6 2 4 1 2 2 0 2 5 ## [31] 2 3 3 3 1 5 4 4 1 4 2 5 3 4 3 3 4 0 3 4 4 3 5 3 2 1 1 2 3 4 ## [61] 2 5 2 3 2 4 2 3 4 1 5 2 5 2 2 3 5 5 2 4 6 3 4 2 2 4 2 4 1 2 ## [91] 1 2 1 3 5 4 4 3 2 4 ``` --- ## Frequency distribution varying lambda .small[ ```r set.seed(0) # so results are reproducible poissonL3 <- rpois(n = 5000, lambda = 3) poissonL10 <- rpois(n = 5000, lambda = 10) poissonL20 <- rpois(n = 5000, lambda = 20) ``` ] .tiny[ .pull-left[ ```r data.frame(poissonL3) %>% rename(outcome = poissonL3) %>% bind_cols(lambda = 3) %>% bind_rows( data.frame(poissonL10) %>% rename(outcome = poissonL10) %>% bind_cols(lambda = 10) ) %>% bind_rows( data.frame(poissonL20) %>% rename(outcome = poissonL20) %>% bind_cols(lambda = 20) ) %>% ggplot(aes(x = outcome, fill = as.factor(lambda))) + geom_histogram(binwidth = 1, position = "identity", alpha = .7) + labs( x = "Number of occurrences", y = "Frequency", title = "5000 samples each from \nPoisson(3), Poisson(10), Poisson(20)", fill = "Lambda" ) ``` ] ] .pull-right[ <img src="lecture18_files/figure-html/unnamed-chunk-21-1.png" width="100%" style="display: block; margin: auto;" /> ] --- ## Exercises An insurance agency determines that 70% of individuals do not exceed their deductible. - Suppose the insurance agency is considering a random sample of four individuals they insure. What is the probability that exactly one of them will exceed the deductible? -- - What is the probability that 3 of 8 randomly selected individuals will have exceeded the insurance deductible, i.e., that 5 of 8 will not exceed the deductible? --- ## Exercises A very skilled court stenographer makes one typographical error (typo) per hour on average. - What probability distribution is most appropriate for calculating the probability of a given number of typos this stenographer makes in an hour? - What are the mean and the standard deviation of the number of typos this stenographer makes? - Would it be considered unusual if this stenographer made 4 or more typos in a given hour? - Calculate the probability that this stenographer makes at most 2 typos in a given hour. --- ## Recall: Continuous random variables <img src="img/density.png" width="40%" style="display: block; margin: auto;" /> - Probability distribution for a discrete random variable: **probability mass function** - Continuous random variable: **probability density functions** - For a continuous random variable, probability for any exact value is zero - Instead, we think about probabilities in ranges. - `\(P(a \leq X \leq b)\)` is the area under the density function between `\(a\)` and `\(b\)`. --- ## Normal Distribution - The **normal distribution** is an example of a continuous distribution - It is a very important distribution and one of the primary inferential tools in statistics - Many **natural phenomenon** approximate the normal distribution, such as weight, height, blood pressure, annual rainfall - Commonly called the *Gaussian distribution* after [Carl Friedrich Gauss](https://en.wikipedia.org/wiki/Carl_Friedrich_Gauss) - Also sometimes called a *bell curve* --- ## Illustration: Shoe sizes - Mickle et al (2010 *Footwear Science*) showed the following bimodal distribution of shoe sizes in the US. <img src="img/bimodalshoes.png" width="80%" style="display: block; margin: auto;" /> Note that standard shoe sizes are discrete. --- ## Illustration: Shoe sizes - Let `\(X\)` represent the shoe size for wearers of men's shoes - (Hypothetical) probability distribution of shoe sizes of wearers of men's shoes. <img src="lecture18_files/figure-html/unnamed-chunk-24-1.png" width="60%" style="display: block; margin: auto;" /> --- ## Illustration: Shoe sizes What is the probability of a customer wanting a men's shoe size smaller than 9? <img src="lecture18_files/figure-html/unnamed-chunk-25-1.png" width="60%" style="display: block; margin: auto;" /> --- ## Smaller Shoes .pull-left[ ``` ## size probability ## 5.5 0.0001 ## 6.0 0.0006 ## 6.5 0.0012 ## 7.0 0.0032 ## 7.5 0.0081 ## 8.0 0.0180 ## 8.5 0.0334 ## 9.0 0.0556 ## 9.5 0.0805 ## 10.0 0.1072 ## 10.5 0.1202 ``` ] .pull-right[ ``` ## size probability ## 11.0 0.1326 ## 11.5 0.1247 ## 12.0 0.1109 ## 12.5 0.0807 ## 13.0 0.0550 ## 13.5 0.0345 ## 14.0 0.0182 ## 14.5 0.0086 ## 15.0 0.0050 ## 15.5 0.0012 ## 16.0 0.0004 ``` ] The probability of a random men's shoe wearer having a shoe size less than 9 in this population is 0.0646. What is the probability of shoe size 10-11.5? --- ## Moving to Continuous Distributions - Now suppose we could get *really* well-fitting shoes, using quarter sizes (9, 9.25, 9.5, 9.75, ...) or even tenth sizes (9, 9.1, 9.2, ...), or shoes specifically made to fit your feet perfectly. - As the number of sizes increases, the bar widths become narrower -> probability distribution of continuous random variable .pull-left[ <img src="lecture18_files/figure-html/normal-1.png" width="90%" style="display: block; margin: auto;" /> ] .pull-right[ This is a **probability density function**. ] --- ## Moving to Continuous Distributions - Probability density function can be used to get the probability of any range of continuous shoe sizes <img src="lecture18_files/figure-html/unnamed-chunk-26-1.png" width="60%" style="display: block; margin: auto;" /> E.g., probability of shoe size being less than 9 (shaded area) --- ## Moving to Continuous Distributions <img src="lecture18_files/figure-html/unnamed-chunk-27-1.png" width="40%" style="display: block; margin: auto;" /> - How do we find this area of interest? - Calculus! `$$P(a \leq X \leq b)=\text{area between a and b below the curve}=\int_a^b f(x)dx$$` where `\(f(x)\)` represents the density curve - In this course, we will use R --- ## Normal Distribution - **Symmetric, bell-shaped** - Characterized by the mean, `\(\mu\)`, and the standard deviation, `\(\sigma\)` (or variance, `\(\sigma^2\)`) - For the normal distribution, the **density function** is given by `$$f(x)=\frac{1}{\sqrt{2\pi\sigma^2}}e^{-\frac{1}{2}\frac{(x-\mu)^2}{\sigma^2}}$$` - Notation: `\(N(\mu,\sigma^2)\)` - The normal distribution with mean 0 and standard deviation 1 is called the **standard normal distribution**. It is commonly denoted `\(Z \sim N(0, 1)\)`. --- ## Probability density function for Normal Distribution - Like `dbinom()` and `dpois()`, `dnorm()` in R gives us the probability density function - Here instead of `\(P(X = x)\)`, it is the **value of the probability density function**, `\(f(x)\)` on the previous slide, at values that we input - `dnorm()` has arguments `x`, `mean` and `sd`, where `mean` and `sd` are the mean and standard deviation of the normal distribution that we want - **Remember that `\(P(X = x) = 0\)` for a continuous random variable**; the value that `dnorm()` gives us is not a probability but the height of the density function --- ## Probability density function for Normal Distribution ```r dnorm(x = -3:3, mean = 0, sd = 1) ``` ``` ## [1] 0.004431848 0.053990967 0.241970725 0.398942280 0.241970725 ## [6] 0.053990967 0.004431848 ``` .small[ ```r data.frame(x = c(-3, 3)) %>% ggplot(aes(x)) + stat_function(fun = dnorm, args = list(mean = 0, sd = 1)) + labs(title = "Probability distribution of N(0, 1)", y = "f(x)") ``` <img src="lecture18_files/figure-html/unnamed-chunk-29-1.png" width="60%" style="display: block; margin: auto;" /> ] --- ## Normal Distribution varying mean - Which of the three distributions have means 0, 1, and 4? <img src="lecture18_files/figure-html/unnamed-chunk-30-1.png" width="60%" style="display: block; margin: auto;" /> --- ## Normal Distribution varying standard deviation - Which has standard deviation 1, 2, and 4? <img src="lecture18_files/figure-html/unnamed-chunk-31-1.png" width="60%" style="display: block; margin: auto;" /> --- ## Summary - Common probability distributions: Poisson and Normal - Theoretical properties: probability density function, parameters, mean and variance, effect of varying parameters - R functions, e.g.: - `dnorm()` for densities - `pnorm()` for `\(P(X\leq x)\)` - `rnorm()` for random sample - Standard normal distribution
